50A Single Phase EMI Filter with 10Khz-30MHZ Frequency Range for Fitness Equipment

Nom De Marque:	VIIP WeiAiPu
Numéro De Modèle:	VIP4-3A-50:
Nombre De Pièces:	1 PIÈCES
Prix:	Négociable
Détails De L'emballage:	333318
Conditions De Paiement:	T/T

Informations détaillées

Description du produit

Informations détaillées

Lieu d'origine:

Chine

Certification:

CE TUV UL CQC

Taper:

Filtre CEM EMI

Fréquence de fonctionnement:

50/60 Hz

Courant nominal:

Métal

Application:

servomoteur monophasé

Certification:

CE ROHS,ISO TUV

Impédance d'entrée:

500 V CC/100 MOHMIN MINIMUM

Gamme de fréquences:

150 kHz à 30 GHz

Température de stockage:

-40 ℃ ~ + 85 ℃

Article:

Filtre EMI

Fréquence du centre nominal:

50/60Hz, 10KHZ~30MHZ, 50/60Hz ((MHz)

Dimensions:

Varie en fonction du modèle

Port:

Shenzhen

Style de terminaison:

Pions de soudure

Courant nominal:

Différent

Poids:

290 g à 1000 g

Résistance à l'isolation:

≥ 100mΩ

Conforme RoHS:

Humidité:

≤ 95% rh

Capacité d'approvisionnement:

2000 pièces dans 10-15 jours

Mettre en évidence:

50A EMI Filter

Single Phase EMI Filter

10Khz-30MHZ EMI Filter

Description du produit

50A House Appliance AC Line EMI Filter Single Phase 10Khz-30MHZ For Fitness Equipment

House Appliance EMC EMI Filter AC Power Line Filter For Fitness Equipment

EMC EMI Filter Quick Detail:

Item	Power line EMI Filter
Model	VIP4-3A-50
Port	Shenzhen
Package Type	Surface Mount
Nominal Center Frequency	10Khz-30MHZ
Insertion Loss	60~90dB
Input Impedance	50Ω
Rated Voltage	110V/250V
Rated Current	50A
Environmental Temperature	40°C
Temperature Range	-25℃~+85℃
Operating Frequency	50/60HZ
Line to Line	1760VDC
Line to Ground	2000VDC
Samples	Available
MOQ	1 PCS
Price	Negotiated
Lead Time	3~20 days

EMC EMI Filter Features:

High performance with common and differential mode attenuation performance
Various terminal options available
Multiple parts and combinations to meet different customer's EMC tests
380VAC versions also available

EMC EMI Filter Applications:

Electrical and electronic equipment
Single phase servo motor
Datacom equipment
Inverters and converters
Charging post
LED equipment

Single Phase EMI Filter Specifications:

Part No.	Rated Current [A]	250VAC/50Hz @ 20°C Leakage Current [mA]	Physical Dimensions	Electrical Schematics	Terminals	Weight [g]
VIP4-3A-01	1A	<1.5mA	Fig 1	Fig 1	- - -	95
VIP4-3A-03	3A	<1.5mA	Fig 2	Fig 1	- - -	145
VIP4-3A-06	6A	<1.5mA	Fig 3	Fig 1	M4	450
VIP4-3A-10	10A	<2.5mA	Fig 3	Fig 1	M4	550
VIP4-3A-20	20A	<2.5mA	Fig 3	Fig 1	M6	550
VIP4-3A-50	50A	<2.5mA	Fig 3	Fig 1	M6	3300
VIP4-3A-100	100A	<4.0mA	Fig 3	Fig 1	M8	3400
VIP4-3A-150	150A	<4.0mA	Fig 3	Fig 1	M10	3600

Electrical Schematic:

Mechanical Dimension (Unit: mm):

Frequently Asked Questions:

Q: What are the main products of your company?

A: IEC inlet socket EMI filter, single-phase filter, house appliance noise filter, Medical equipment filter, inverter/converter EMC filter and other EMI/EMC ferrite core products.

Q: How is the quality of your product?

A: All our products have passed UL, TUV, CE, ROHS, ISO9001 approval, which ensures the quality of the product.

Q: What services are available for pre-batch orders?

A: Free samples and EMC technical rectification services are supplied before sale.

Q: What services are available after-sale?

A: Free replacement within three months, free maintenance within six years, and life-long maintenance.

Q: Are OEM and ODM services available?

A: Yes, we can accept OEM or ODM customers only if you meet our MOQ request.
